SwimClear Multi-Element Cartridge Filter 425 Sq.Ft

Hayward

SKU: C4030

SwimClear Multi Element cartridge filters capture more dirt for superior water clarity without the need of supplemental media or back-washing, while the industry's lowest head loss reduces energy costs.

Features

SwimClear is also the easiest to service: the Easy-Lok™ ring design, comfort grip handles, and lowest lift height provide fast cleaning and element replacement. SwimClear is an excellent filtration solution for smaller and mid-size pools, spas and water features.

• Industry-leading hydraulic efficiency allows the pump to run at a lower speed or for less time, increasing energy savings
• Easy-Lok ring design allows quick access to internal components for quick and simple maintenance
• Recessed pressure gauge and manual air relief enables user to place head assembly upside down on pool pad, protecting the seal from contamination
• 2” x 2 1/2” union connections make installation and servicing fast and easy
  • EXPERT LINE products can only be purchased through you local pool professional or in-store.
  • 3+ Year Parts and Labor Warranties*

*When sold by a Totally Hayward® partner. Exclusions, other terms and conditions may apply.

Brand Hayward
Cartridge Yes
Channel Expert Line
Effective Filtration Area 425 SQFT
Filter Type Cartridge
GTIN 610377123952
Labor Warranty None
Number of Filter Elements 4
Pallet Qty 8
Parts Warranty 3-year
Pool Type In Ground
Pressure Gauge Yes
Product Dimensions 40.5 " x 24 " x 24 "
Public Design Flow Rate 567.8115
Quantity 1
Series Filters SwimClear
Shipping Dimensions 41.8 " x 24.6 " x 23.1 "
Shipping Height 41.8 in
Shipping Length 23.1 in
Shipping Weight 83 lb
Shipping Width 24.6 in
Tank Type GFR
Turnover 10 Hours 90000 GPM
Turnover 8 Hours 72000 GPM
