StarClear Plus Cartridge Filter 90 Sq.Ft.

Hayward

SKU: C9002

StarClear Plus single element cartridge filters offer excellent quality, value and convenience.

Features

StarClear Plus filters offer quality, value and convenience in cartridge filtration. Because of their durable construction, they can handle the most demanding applications and environmental conditions. The precision engineered core provides extra strength and maximum flow. StarClear Plus filters deliver proven performance and value.

Features and Benefits

  • Filter tanks made from durable glass reinforced co-polymer material to meet the demands of the toughest applications and environmental conditions, including in-floor cleaning systems
  • Single piece injection-molded base and body provides added strength for reliable, corrosion-free performance
  • Single locking knob securely fastens head to filter tank, eliminating bolts or clamps
  • Extra-large cartridge element with precision engineered core provides extra-strength and maximum flow
  • Elevated, filtered water collector and debris sump prevents accidental by-pass of heavy debris to pool when cartridge is removed for cleaning
  • 2" FIP connections for plumbing versatility
  • 1⁄2" FIP filter drain for fast draining. Also accepts a standard spigot valve
  • EXPERT LINE products can only be purchased through your local pool professional or in-store.  Exclusions, other terms, and conditions may apply.

Exclusions, other terms and conditions may apply.

Brand Hayward
Cartridge Yes
Channel Expert Line
Effective Filtration Area 90 ft.²
Filter Type Cartridge
GTIN 610377205818
Warranty - Labor None
Master Carton Qty 1
Number of Filter Elements 1
Pallet Qty 18
Warranty - Parts 1-year
Pool Type In Ground
Pressure Gauge Yes
Quantity 1
Series Filters StarClear Plus
Sub Brand N/A
Tank Type GFR
Valve Included N/A
Parts Details

Click on the part number in the diagram to display the details.

Line Drawings

Questions & Answers

12 answered question(s)

06/24/26

Q: Correct Hayward P/N for the main rubber seal for a P90 Star-Clear filter! The ones I purchase on Amazon will not let me open or close the lid without excess force! (Way too tight) Thanks

A:
You need a CX900F o-ring for a C9002 filter

By Hayward Support

06/24/26

Q: I have this filter and that top has a hole is there a replacement part

A:
Yes, the replacement top is part # CX900B We do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: What size filter and housing do I need for a 17000gallon inground pool

A:
Hi, since each pool is different, we suggest you consult with a local Hayward Authorized Pool Professional for sizing your filter. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: I currently have a C750 filter assembly with 1-1/2” water connections. Does the C9002 filter assembly come with adapters to fit the 2” inlet and outlet on the filter base, or do I need to purchase those separately? Do you have theses adapters in stock? Do you have a p/n?

A:
Hi, the filter does not come with adapters. You can purchase reducer fittings from a local hardware. We do not sell them.

By Hayward Support

06/24/26

Q: What is the difference between Model C900 and C9002?

A:
The C9002 has 2" water connections. The C900 had 1 1/2" connections. The C900 is obsolete.

By Hayward Support

06/24/26

Q: Can I use this cartridge in line with a 1.5 hp pool pump

A:
yes you can

By Hayward Support

06/24/26

Q: Where can I purchase a Filter Head Replacement with Directional Vent Valve for Hayward Star C9002?

A:
Hi, we do not sell direct. You can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: do cartridge filters require D E?

A:
They do not.

By Hayward Support

06/24/26

Q: I have a Hayward star clear plus C 9002 filter 90 sq ft. What model has replaced this?

A:
Hi, the C9002 is still available.

By Hayward Support

06/24/26

Q: I would like to speak with somone ragarding my I would like to speak to someone about my filter and what I should for repair c900 Filter.

A:
For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

06/24/26

Q: I need to drain 1foot of pool water to balance pool water. can you provide me the part # i need to so I can attach a garden hose to my C9002 Cartridge Filter so I can deflect the water to the street; away from septic area. Pool store suggested a drain plug adaptor that i can remove the drain plug and screw in the adaptor to attach the hose to, but I cannot seem to find this part after searching internet. If i can't do garden hose, other suggestions welcome.

A:
Hi, we do not have an adapter for this purpose.

By Hayward Support

06/24/26

Q: Can I purchase cartridge filter CX900RE from your web site? I have model#C9002 serial# 21122306004271008.

A:
Hi, we do not sell direct, but you can find a list of local dealers by clicking on the Dealer Locator tab in the upper right on the home page of our website Hayward.com

By Hayward Support
