AquaRite S3 Omni Salt System w/ 25,000 gallon Clear TurboCell

Hayward

SKU: AQRS325OMNI

AquaRite® S3 Omni takes salt sanitization to the next level, combining industry-leading performance with fully integrated pool and spa automation.

Features

AquaRite® S3 Omni takes salt sanitization to the next level, combining industry-leading performance with fully integrated pool and spa automation. With S3 Omni, you gain full control of your backyard experience via the intuitive OmniLogic® app, or voice control devices. Manage ColorLogic® lighting with OmniDirect Mode™, or monitor water chemistry with optional pH and ORP sensing. Expand anytime with smart relays, Wi-Fi, acid feed systems, and more.

Features and Benefits

  • LCD color display for built-in control of chlorine levels, heater and variable-speed pump*
  • Clear TurboCell salt cell for easy inspection
  • Operates over a broad range of salt levels, 800-8000 ppm
  • Pool cover detect capabilities
  • Auto voltage select for easier installation
  • Full control of virtually any pool or spa feature via the external control panel, OmniLogic® app, or voice control devices**
  • Valve ports to automatically switch to Spa mode (GVA-24 automatic actuators sold separately)
  • ColorLogic lighting control with OmniDirect Mode™
  • pH and ORP sensing capabilities (probes sold separately)
  • Expand at any time with easy-to-add accessories from smart relays, pH sensing, Wi-Fi connectivity and more
  • Configurable for future upgrades
  • Control and set schedules for 3x variable-speed pumps, 2x heaters, and/or 2 high power relays
  • Capable of controlling an acid feed tank

NOTE: *Single-speed pump control via Smart Relay, HLH485RELAY, sold separately, **Voice control devices are not included

  • EXPERT LINE products can only be purchased through your local pool professional or in-store.  Exclusions, other terms, and conditions may apply.

Exclusions, other terms and conditions may apply.

Application New Construction, Renovation, Aftermarket
Brand Hayward
Channel Expert Line
GTIN 610377414654
Warranty - Labor None
Master Carton Qty 1
Pallet Qty 18
Warranty - Parts 3-year
Pool Type In Ground
Shipping Dimensions 15 " x 16 " x 19 "
Shipping Weight 24.7 lb
Sub Brand N/A
Series Water Quality AquaRite S3 Omni
Salt (lbs/day) 1.45
Water Quality Type Salt Chlorinators
Twist Lock No

Questions & Answers

11 answered question(s)

06/24/26

Q: Hello. Does this control panel have a wifi feature? If not can you purchase parts separately? With wifi can you control the heater, lights , pump ? Upgrading my pool changing to saltwater. Would you recommend this controls panel? Would light to have it control all my pool equipment via wifi

A:
Yes, the AQRS3 omni can connect to a wifi network. We do not sell directly through our website. Please use our website's dealer locator to find your closest dealer. A dealer can assist you in finding the product that fits your needs.

By Hayward Support

06/24/26

Q: My screen is totally black it's still under warranty, do you have any trouble shooting instructions for this? If so please send

A:
Please use our website's dealer locator to find the closest Hayward Authorized Service Center(HASC). A HASC may be needed to troubleshoot this issue.

By Hayward Support

06/24/26

Q: What is the link to upgrade the firmware for this product? Do you have to do both the main board and the display also? Are they separate updates?

A:
Here is the link: https://hayward.com/support/resources/firmware

By Hayward Support

06/24/26

Q: Hi, the display panel of my AQRS325 is not working. it's totally black. changed fused but still not functioning. There is current going to the main panel. Is there a replacement of this part? thanks

A:
The part number for a replacement display is GLXS3DISPLAY.

By Hayward Support

06/24/26

Q: How many amps do I run to the Omni? I have 200k btu gas heater, tri star 1.1 hp pump, large Hayward led multi color pool light and the Omni salt system.

A:
Hello, someone from our technical team will be in contact with you shortly.

By Hayward Support

06/24/26

Q: Our salt cell has brown haze in the end. This is a new fiberglass pool install (we have city water). It’s only been 3 weeks. It changed 1 week ago from blueish white to brown on the ends. We backwashed today and it still looks brown in the ends of the tube. What has happened?

A:
Hello, someone from our technical team will be in contact with you shortly.

By Hayward Support

06/24/26

Q: Im having a hard time locating a reputable dealer for this product, our zip is 60451. i would like a dealer knowledgeable in this product as well as the supporting pieces to make it very convenient to use.

A:
Hello, someone from our tech team will be in contact with you shortly.

By Hayward Support

06/24/26

Q: is it ok to upsize your system?

A:
Someone from our technical team will be in contact with you soon.

By Hayward Support

06/24/26

Q: I asked for a part number for the fuse in my S3, it is LT3.15AT250V and you answered with GLXS3FUSE. That is your part number and are out of stock. I need the fuse now, so can I assume if I buy the LT3.15AT250V slow blow 5mm x 20 mm it will work. I can't check my chlorination without it.

A:
Hi. Yes, you can use LT3.15AT250V.

By Hayward Support

06/24/26

Q: My Aquarite S3 blew the circuit board fuse that powers LED display. The Part number looks like LT3.15AT250V. DO you have a part number o the BUSMAn or Littelfuse part number? My unit is only 3 months old and under warranty. 240-367-4488 ranboots@yahoo.com

A:
We have a part number for replacement fuses. That part number is GLXS3FUSE.

By Hayward Support

06/24/26

Q: I'm thinking about adding a salt generator to my existing pool that has a Hayward DE Filter. The pool is a 33,000 gallon pool. Does Hayward make a model for my size pool? Also do you have installers in my area (95628)? Thanks

A:
Yes, we make a version of this product that will support up to a 40000-gallon pool. That part number is AQRS340OMNI. Please use the dealer locator on our website to find a dealer near you.

By Hayward Support
